Precision Engineered
Schrick 272° Camshaft – BMW M20 2.0–2.5L 12V
478,95 €
Only 5 left in stock
1
Precision Fit
Quality Checked
Fast Dispatch
Description
Schrick 272° camshaft for BMW M20 2.0–2.5 litre, 12-valve, six-cylinder engines. The 272° Synchron profile features matching intake and exhaust duration, with 11 mm valve lift on both sides.
Specifications
- Brand: Schrick
- Manufacturer part number: 005601720-00
- Engine family: BMW M20
- Engine capacity: 2.0–2.5 litres
- Configuration: six cylinders, 12 valves
- Camshaft profile: 272° Synchron
Camshaft Technical Data
Camshaft for intake and exhaust.
| Specification | Intake | Exhaust |
|---|---|---|
| Duration | 272° | 272° |
| Lobe centreline | 111° | 111° |
| Cam lift | 7.0 mm | 7.0 mm |
| Valve lift | 11 mm | 11 mm |
| Specification | Intake | Exhaust |
|---|---|---|
| Opening timing | 25° | 67° |
| Closing timing | 67° | 25° |
| Valve lift at TDC | 1.6 mm | 1.6 mm |
| Valve clearance | 0.25 mm | 0.25 mm |
Compatibility
Confirm suitability for your exact engine and build before ordering. Contact Ge-Tech Engineering if you need help checking compatibility.
Professional installation and verification of the required valvetrain components are recommended. Check applicable road-use approval requirements before installation; do not assume this performance camshaft is approved for road use.
Images are illustrative; the original photographs show a different Schrick camshaft reference.
